Water Supply » Desalination Plants

What you'll learn this session

Study time: 30 minutes

What desalination is and why it's important for water supply
The main methods of desalination (thermal and membrane processes)
Environmental impacts of desalination plants
Economic considerations of desalination
Case studies of desalination around the world
Future trends and sustainable approaches to desalination

Introduction to Desalination Plants

Desalination is the process of removing salt and other minerals from seawater or brackish water to make it suitable for human consumption and other uses. As freshwater scarcity becomes a growing concern globally, desalination offers a solution by tapping into the vast reserves of seawater that cover more than 70% of our planet.

Key Definitions:

Desalination: The process of removing salt and minerals from seawater to produce fresh water.
Brackish water: Water that has more salinity than freshwater but less than seawater.
Brine: The highly concentrated salt solution that remains after desalination.
Potable water: Water that is safe to drink.

Quick Facts – Desalination

There are over 18,000 desalination plants worldwide
They produce more than 95 million cubic metres of water daily
The largest plants can provide water for millions of people
Middle Eastern countries rely heavily on desalination for water supply

Main Desalination Methods

There are two primary approaches to desalination: thermal processes and membrane processes. Each has distinct advantages, disadvantages and energy requirements.

♥ Thermal Desalination

Thermal desalination processes involve heating seawater and collecting the freshwater vapour that evaporates, leaving the salt behind.

Main Types:

Multi-Stage Flash Distillation (MSF): Water is heated and passed through chambers of progressively lower pressure, causing it to "flash" into steam which is then condensed.
Multiple-Effect Distillation (MED): Uses multiple evaporation chambers (effects) where vapour from one chamber heats the next.
Vapour Compression Distillation (VCD): Compresses water vapour to generate heat for evaporation.

♦ Membrane Desalination

Membrane processes use semi-permeable membranes to separate salt from water without a phase change.

Main Types:

Reverse Osmosis (RO): Applies pressure to force water through a membrane that blocks salt and impurities.
Electrodialysis (ED): Uses electrical current to move salt ions through membranes, leaving freshwater behind.
Forward Osmosis (FO): Uses the natural osmotic pressure difference to draw water through a membrane.

How Reverse Osmosis Works

Reverse Osmosis (RO) is the most widely used desalination method today. Let's look at how it works:

Pre-treatment: Seawater is filtered to remove large particles, adjusted for pH and treated with chemicals to prevent fouling of the membranes.
Pressurisation: The water is pressurised using high-pressure pumps (typically 55-85 bar for seawater).
Separation: The pressurised water passes through semi-permeable membranes that allow water molecules through but block salt ions and other impurities.
Post-treatment: The desalinated water is treated to adjust pH, add minerals and disinfect it before distribution.
Brine disposal: The concentrated salt solution (brine) is disposed of, typically back into the sea.

✓ Advantages of RO

Lower energy consumption than thermal methods
Smaller physical footprint
Can be scaled to different sizes
Improving technology is reducing costs

✗ Disadvantages of RO

Membrane fouling and replacement costs
Still energy-intensive
Produces concentrated brine waste
Higher maintenance requirements

⊕ Energy Requirements

Modern RO plants: 3-4 kWh per m³
Thermal plants: 10-15 kWh per m³
Energy recovery devices can reduce consumption by up to 60%
Renewable energy integration is increasing

Environmental Impacts of Desalination

While desalination provides a valuable water source, it comes with significant environmental considerations:

Marine Ecosystem Impacts

Intake systems: Can trap and kill marine organisms (impingement and entrainment).
Brine discharge: The concentrated salt solution can harm marine life near outfall points. Brine is typically 1.5-2 times saltier than seawater and may contain chemicals from pre-treatment.
Temperature changes: Thermal plants discharge warmer brine, affecting local ecosystems.
Chemical pollution: Cleaning chemicals, anti-scaling agents and anti-fouling compounds can harm marine life.

Climate and Energy Impacts

Carbon emissions: High energy use often means high carbon footprint, especially if powered by fossil fuels.
Land use: Plants require coastal land that might otherwise serve as natural habitat.
Noise pollution: High-pressure pumps create noise that can affect nearby communities and wildlife.

Economic Considerations

The economics of desalination are complex and depend on many factors:

£ Cost Factors

Capital costs: Building a large-scale plant costs hundreds of millions of pounds.
Energy costs: Typically 30-50% of operating expenses.
Maintenance: Membrane replacement, cleaning and repairs.
Labour: Skilled technicians and engineers required.
Water production cost: Typically £0.50-£1.50 per cubic metre, depending on location and technology.

∞ Comparing Water Sources

Cost comparison with other water sources (per cubic metre):

Conventional water treatment: £0.10-£0.30
Groundwater: £0.20-£0.40
Water recycling/reuse: £0.30-£0.70
Desalination: £0.50-£1.50
Water tankers (emergency): £2.00-£5.00

Case Study: The Thames Water Desalination Plant, London

The UK's first major desalination plant opened in Beckton, East London in 2010. It cost £250 million to build and can provide up to 150 million litres of drinking water per day – enough for nearly 1 million people. The plant uses reverse osmosis technology and was designed to operate during drought conditions when London's reservoirs are low. It draws brackish water from the Thames Estuary at high tide when the salt content is lower. The plant only operates when needed, serving as drought insurance for London's water supply.

Environmental considerations include:

Powered partly by biodiesel to reduce carbon footprint
Careful management of brine discharge back into the Thames
Energy recovery systems to improve efficiency

Global Case Studies

Desalination Around the World

Saudi Arabia: The world's largest producer of desalinated water, with about 30% of global capacity. The Ras Al-Khair plant can produce 1 million cubic metres daily, using both thermal and RO technologies.
Israel: Relies on desalination for 80% of its domestic water. The Sorek plant is one of the world's largest and most efficient RO facilities.
Australia: Built several major plants during the Millennium Drought. The Melbourne Desalination Plant can provide up to 150 billion litres of water annually.
Singapore: Uses desalination as part of its "Four National Taps" water strategy, alongside imported water, rainwater catchment and recycled water (NEWater).

Future Trends and Sustainability

The future of desalination focuses on making the process more sustainable and affordable:

♪ Energy Innovations

Solar-powered desalination
Wind energy integration
More efficient energy recovery
Low-pressure membrane systems

⊛ Environmental Solutions

Zero liquid discharge systems
Brine mining for valuable minerals
Subsurface intakes to protect marine life
Diffuser technology for brine disposal

&Yen; Economic Improvements

Longer-lasting membranes
Automated monitoring systems
Modular, scalable designs
Public-private partnerships

Summary: The Role of Desalination in Water Security

Desalination plays an increasingly important role in global water security, especially in water-stressed regions. While it remains more expensive than conventional water sources, technological improvements continue to reduce costs and environmental impacts. As climate change threatens traditional freshwater supplies, desalination provides a climate-resilient alternative that isn't dependent on rainfall patterns.

For many coastal communities facing water scarcity, the question is no longer whether to use desalination, but how to implement it in the most sustainable and cost-effective way. The future of desalination will likely involve smaller, more energy-efficient plants powered by renewable energy, with improved methods for managing environmental impacts.

🧠 Test Your Knowledge!
