Earthquakes and Volcanoes » Global Plate Distribution

What you'll learn this session

Study time: 30 minutes

The structure and distribution of tectonic plates across the globe
Different types of plate boundaries and their characteristics
How plate movement relates to earthquake and volcanic activity
Major tectonic plates and their locations
The evidence for plate tectonics theory
Real-world examples of plate boundaries and their environmental impacts

Introduction to Global Plate Distribution

Our planet's surface is not one solid piece but rather a jigsaw puzzle of massive slabs called tectonic plates. These plates float on the semi-molten layer beneath them and are constantly moving albeit very slowly (about 2-10 cm per year, similar to how fast your fingernails grow!). This movement explains why earthquakes and volcanoes occur where they do and helps us understand the shape of our continents and oceans.

Key Definitions:

Tectonic plates: Large, relatively rigid sections of the Earth's lithosphere that move across the asthenosphere.
Lithosphere: The rigid outer layer of the Earth, including the crust and upper mantle.
Asthenosphere: The semi-molten layer beneath the lithosphere on which tectonic plates move.
Plate boundary: The edge where two tectonic plates meet.

The Earth's Structure and Plate Tectonics

To understand plate tectonics, we need to know about the Earth's layers. Our planet has four main layers: the inner core, outer core, mantle and crust. The lithosphere (which contains the tectonic plates) includes the crust and the uppermost part of the mantle.

🌎 Earth's Layers

Crust: The thin outer layer (5-70km thick) where we live.

Mantle: The thick, semi-solid layer beneath the crust.

Outer Core: Liquid metal layer surrounding the inner core.

Inner Core: Solid metal centre of the Earth.

🔍 Plate Tectonics Theory

The theory of plate tectonics was only accepted in the 1960s, though the idea that continents move (continental drift) was proposed by Alfred Wegener in 1912. Wegener noticed that continents seemed to fit together like puzzle pieces, but he couldn't explain how they moved.

Modern technology has confirmed that plates do indeed move, driven by convection currents in the mantle.

Major Tectonic Plates

The Earth's surface is divided into about 7 major plates and numerous smaller ones. The major plates include:

Pacific Plate: The largest plate, mostly beneath the Pacific Ocean.
North American Plate: Contains most of North America and part of the Atlantic Ocean.
Eurasian Plate: Contains most of Europe and Asia.
African Plate: Contains the African continent and surrounding oceanic crust.
South American Plate: Contains the South American continent and surrounding oceanic crust.
Indo-Australian Plate: Contains India, Australia and surrounding oceanic crust (sometimes considered as two separate plates).
Antarctic Plate: Contains the Antarctic continent and the seafloor around it.

Types of Plate Boundaries

Where plates meet, different types of boundaries form depending on how the plates move relative to each other. These boundaries are associated with specific geological features and hazards.

💥 Divergent Boundaries

Plates move away from each other, creating gaps where magma rises to form new crust.

Features: Mid-ocean ridges, rift valleys

Example: Mid-Atlantic Ridge

Hazards: Volcanic eruptions, minor earthquakes

💨 Convergent Boundaries

Plates move towards each other, causing one plate to sink beneath another or creating mountain ranges.

Features: Deep ocean trenches, mountain ranges, volcanoes

Example: Andes Mountains (South American Plate and Nazca Plate)

Hazards: Major earthquakes, explosive volcanoes, tsunamis

🔃 Transform Boundaries

Plates slide past each other horizontally.

Features: Fault lines, displaced streams

Example: San Andreas Fault (North American and Pacific Plates)

Hazards: Strong earthquakes

Convergent Boundaries in Detail

Convergent boundaries come in three types, each with distinct characteristics:

🌊 Oceanic-Continental Convergence

When an oceanic plate meets a continental plate, the denser oceanic plate subducts (sinks) beneath the continental plate. This creates deep ocean trenches and volcanic mountain ranges on the continental plate.

Example: The Andes Mountains formed as the Nazca Plate subducts beneath the South American Plate.

🌋 Oceanic-Oceanic Convergence

When two oceanic plates collide, one subducts beneath the other, creating deep trenches and volcanic island arcs.

Example: The Mariana Trench and the volcanic islands of Japan formed through oceanic-oceanic convergence.

⛰ Continental-Continental Convergence

When two continental plates collide, neither can subduct because continental crust is less dense than the mantle. Instead, the crust buckles and folds, creating massive mountain ranges.

Example: The Himalayas formed as the Indo-Australian Plate collided with the Eurasian Plate.

Evidence for Plate Tectonics

Scientists have gathered various types of evidence supporting plate tectonics theory:

Jigsaw fit of continents: The east coast of South America fits against the west coast of Africa.
Fossil evidence: Similar fossils found on continents now separated by oceans.
Rock type and age: Similar rock formations and ages found on matching coastlines.
Paleomagnetism: The magnetic orientation in rocks shows that continents have moved over time.
Seafloor spreading: New crust forms at mid-ocean ridges and spreads outward.
Direct measurement: GPS technology can now measure plate movement directly.

Case Study Focus: The Ring of Fire

The Pacific Ring of Fire is a horseshoe-shaped belt of intense earthquake and volcanic activity that surrounds much of the Pacific Ocean. It's where about 75% of the world's active volcanoes are located and 90% of the world's earthquakes occur.

This pattern exists because the Pacific Plate is surrounded by convergent and transform boundaries with other plates. As the Pacific Plate subducts beneath surrounding plates, it creates conditions perfect for earthquakes and volcanic eruptions.

Key locations: Japan, Philippines, Indonesia, New Zealand, Alaska, western coast of North and South America.

Recent events: The 2011 Tōhoku earthquake and tsunami in Japan (magnitude 9.1) occurred along the Japan Trench where the Pacific Plate subducts beneath the Eurasian Plate.

Hot Spots: Exceptions to the Rule

Not all volcanic activity occurs at plate boundaries. Hot spots are areas where magma from deep within the mantle rises up through the plate above. As the plate moves over the stationary hot spot, it creates a chain of volcanoes.

Example: The Hawaiian Islands formed as the Pacific Plate moved over a hot spot. The oldest islands (to the northwest) formed first, while the newest island (Hawaii) sits directly over the hot spot today. The next Hawaiian island (Loihi) is currently forming underwater and will emerge above sea level in about 10,000-100,000 years.

Environmental Impacts of Plate Tectonics

Plate tectonics shapes our environment in many ways:

Landform creation: Mountains, valleys, islands and ocean trenches
Natural hazards: Earthquakes, volcanic eruptions, tsunamis
Mineral resources: Many valuable minerals form at plate boundaries
Climate influence: Mountain ranges affect weather patterns and rainfall
Biodiversity: Isolated landmasses lead to unique species evolution

Did You Know?

The Earth's continents will look completely different in the future! Scientists predict that in about 250 million years, the continents might form a new supercontinent called "Pangaea Ultima" as the Atlantic Ocean closes and the Pacific Ocean expands.

Plate tectonics is rare in our solar system. While Venus and Mars have some volcanic features, Earth is the only planet known to have active plate tectonics, which may be crucial for supporting complex life.
