lessonTitle: Graph, Chart and Diagram Selection
Graphs, charts and diagrams are essential tools in geography. They help us make sense of complex data and show patterns that might not be obvious from raw numbers. Choosing the right visual representation can make your geographical analysis much clearer and more effective.
Key Definitions:
Different types of data need different types of visual representation. Here's how to choose the right one:
Best for: Showing changes over time or continuous data.
Examples in Geography: Temperature changes, population growth, rainfall patterns over months/years.
When to use: When you want to show trends, patterns or relationships between continuous variables, especially over time.
Tip: Always label your axes clearly and include a title!
Best for: Comparing discrete categories or showing frequency distributions.
Examples in Geography: Comparing rainfall in different regions, employment in different sectors, land use types.
When to use: When you want to compare different categories or show the distribution of a single variable.
Tip: Bars can be vertical (column charts) or horizontal - horizontal works better for long category names!
Best for: Showing proportions of a whole or percentage distributions.
Examples in Geography: Land use percentages, energy sources, employment sectors, population structure.
When to use: When you want to show how a whole is divided into parts and the relationship between those parts.
Tip: Works best with fewer than 7 categories - too many slices become hard to interpret!
Best for: Showing relationships between two variables.
Examples in Geography: GDP vs life expectancy, temperature vs altitude, rainfall vs crop yield.
When to use: When investigating correlations or relationships between two sets of data.
Tip: You can add a trend line (line of best fit) to show the overall pattern more clearly.
Maps where areas are shaded according to statistical variables (like population density or GDP).
Best for: Showing spatial patterns and regional variations.
Maps with lines showing movements (like migration or trade), where thickness represents volume.
Best for: Showing movement, connections and relationships between places.
Maps with symbols sized according to values (like circles for city populations).
Best for: Showing variations in magnitude at specific locations.
Bar charts showing age and gender distribution of a population.
Best for: Analysing population structure and making demographic comparisons.
Combined bar and line graphs showing monthly temperature and precipitation.
Best for: Comparing climate patterns in different locations.
Diagrams showing a "slice" through a landscape, river valley, or other feature.
Best for: Illustrating changes in elevation, geology, or land use across an area.
When deciding which graph, chart or diagram to use, ask yourself these questions:
Even the best data can be misrepresented if you choose the wrong visual format:
In your iGCSE Geography exam, you might be asked to:
Remember: Choosing the right visual representation can earn you method marks, even if your drawing skills aren't perfect!
| If you want to show... | Consider using... |
|---|---|
| Changes over time | Line graph, time series |
| Comparisons between categories | Bar chart, column chart |
| Parts of a whole | Pie chart, 100% stacked bar chart |
| Relationships between variables | Scatter graph, correlation diagram |
| Spatial patterns | Choropleth map, dot density map |
| Population structure | Population pyramid |
| Climate data | Climate graph (combined temperature line and rainfall bars) |
| Processes or cycles | Flow diagram, cycle diagram |
Let's look at a real geographical scenario to help you decide which visual representation to use:
You've collected the following data about a river's discharge (in cubic metres per second) throughout the year:
Jan: 45, Feb: 50, Mar: 65, Apr: 80, May: 60, Jun: 40, Jul: 30, Aug: 25, Sep: 35, Oct: 55, Nov: 70, Dec: 60
Best representation: A line graph would be most appropriate here as it shows continuous data changing over time. The x-axis would show months and the y-axis would show discharge in m³/s.
Why not a bar chart? While a bar chart could work, a line graph better shows the continuous nature of the data and makes trends easier to spot.
Why not a pie chart? A pie chart wouldn't be suitable as we're not looking at proportions of a whole, but rather how a single variable changes over time.
Choosing the right graphical representation is a crucial skill in geography. It helps you communicate data clearly and spot patterns that might otherwise be missed. Remember:
With practice, you'll develop an instinct for which visual format works best for different types of geographical data. This skill will serve you well in your iGCSE exams and beyond!
