lessonTitle: Data Collection Sheet Design
Data collection sheets are the backbone of any successful fieldwork investigation. They're the tools you'll use to gather information systematically when you're out in the field. A well-designed data collection sheet can make the difference between collecting useful, accurate data and ending up with a jumbled mess that's difficult to analyse!
Key Definitions:
Imagine trying to remember all your observations from a busy high street survey or a river study without writing anything down! Data collection sheets help you:
Collection sheets provide structure to your investigation and ensure you gather all the information you need systematically. They help you stay focused on your enquiry question and prevent you from forgetting important measurements.
When everyone in your class uses the same data collection sheet, you can combine results to create a larger dataset. This standardisation makes analysis easier and results more reliable, especially for statistical testing.
Your data collection sheet needs to be easy to use in field conditions, which might include rain, wind, or other challenging environments. Remember these principles:
Avoid cluttering your sheet with unnecessary information. Include only what you need to collect for your investigation.
Include brief instructions on how to complete each section. This helps ensure consistency, especially if working in groups.
Arrange your sheet in a logical sequence that matches the order you'll collect data in the field.
Different geographical investigations require different approaches to data collection. Here are some common formats you might use:
Perfect for recording frequency data such as pedestrian counts, traffic surveys, or shop type inventories. They allow you to quickly mark observations with minimal writing.
A traffic survey sheet might include columns for different vehicle types (cars, buses, bicycles) and rows for different time intervals. You simply make a tally mark in the appropriate cell each time a vehicle passes.
This format works well when you need to count multiple categories simultaneously and when speed is important.
These use rating scales to assess subjective aspects of an environment, such as visual quality, noise levels, or perceived safety.
You might create a sheet with categories like 'Litter', 'Building Condition' and 'Green Space', with a rating scale from 1-5 for each. Clear descriptions of what each rating means (e.g., 1 = Very Poor, 5 = Excellent) help ensure consistency.
These provide outlines or grids where you can record visual observations through sketches or mapping.
Include a frame for your sketch, with space to label key features and note important details like direction, weather conditions and time of observation.
Provide a base map with a clear grid system and a key for different land use categories. This allows you to systematically record spatial patterns.
Essential for physical geography fieldwork where you need to record precise measurements.
A river study sheet might include spaces to record channel width, depth at different points, velocity measurements and bedload size. It should clearly indicate the units of measurement (cm, m/s, etc.) and provide space to calculate averages.
Think about how your sheet will be used in the field:
Consider laminating sheets or using waterproof paper if working in wet conditions. Provide clipboards for support.
A4 is standard, but A5 might be more manageable in windy conditions or when space is limited.
Number your sheets and include space for name, date, location and weather conditions on each one.
Advantages: No battery or connectivity issues, easy to use in all weather conditions, no technical skills required.
Disadvantages: Data must be transferred to digital format later, can be damaged or lost, limited space.
Advantages: Data can be uploaded directly for analysis, can include GPS locations, allows for photos and recordings.
Disadvantages: Requires charged devices, may be difficult to use in bright sunlight or rain, potential technical problems.
Even small design flaws can lead to big problems with your data. Watch out for these common issues:
Unclear instructions or categories lead to inconsistent data collection. Be specific about what you're asking people to record.
Trying to collect too much data on one sheet makes it confusing and difficult to use. Focus on what's essential for your enquiry.
Categories that overlap or don't cover all possibilities create confusion. Test your categories before fieldwork.
Never take an untested data collection sheet into the field! Always pilot test your design:
1. Create a draft of your data collection sheet
2. Try using it in conditions similar to your fieldwork (e.g., if counting pedestrians, test it on a busy street)
3. Note any difficulties or confusion you experience
4. Ask others to test it and provide feedback
5. Revise your sheet based on the testing
6. Test again if you've made significant changes
Always design your data collection sheet with analysis in mind. Think about how you'll process the data afterwards:
If you plan to use statistical tests, ensure your data is collected in a format that supports this. For example, if using Spearman's Rank, you'll need numerical data that can be ranked.
Consider what graphs or charts you might create. Ensure your categories and measurements will translate well to visual formats.
Before finalising your data collection sheet, ask yourself:
A group of GCSE Geography students investigated how river characteristics changed downstream at River Bradgate. Their data collection sheet included:
• A header section with site number, GPS coordinates, date, time and weather conditions
• A diagram of the river cross-section with spaces to record width and depth measurements at 1m intervals
• A table to record velocity readings at three points across the channel
• A pebble sampling section with spaces to record the dimensions of 10 randomly selected stones
• A visual assessment scale for bank stability and vegetation cover
The sheet was printed on waterproof paper and attached to clipboards. This design allowed them to efficiently collect comparable data at five sites along the river's course.
