Understanding Infiltration and Percolation
When it rains, water doesn't just flow across the surface of the land. Much of it soaks into the ground through processes that are vital to the water cycle and river systems. You met precipitation and interception in The Drainage Basin and the Water Cycle: Precipitation and Interception. This lesson follows the rain that reaches the ground: it either soaks in (infiltration and percolation) or runs across the surface (overland flow) until it reaches a river and becomes channel flow.
Key Definitions:
- Infiltration: The process by which water on the ground surface enters the soil.
- Percolation: The movement of water through soil pores and rock fractures after infiltration has occurred.
- Infiltration Rate: The speed at which water enters the soil, usually measured in mm per hour.
- Infiltration Capacity: The maximum rate at which water can enter the soil.
- Permeability: The ability of a rock or soil to allow water to pass through it.
- Porosity: The percentage of rock or soil that consists of void spaces.
- Overland flow: The movement of water over the land surface before it enters a channel.
- Channel flow: The movement of water within a defined river channel.
๐ง Infiltration Process
Infiltration begins when water hits the soil surface. The rate at which water can enter the soil depends on several factors:
- Soil type and structure
- Soil moisture content
- Vegetation cover
- Slope gradient
- Rainfall intensity and duration
Sandy soils generally have high infiltration rates (20-30mm/hr), while clay soils have much lower rates (1-5mm/hr).
โฌ๏ธ Percolation Process
Once water has infiltrated the soil, it percolates downward due to gravity. This process is affected by:
- The size of pore spaces in soil and rock
- The presence of impermeable layers
- Rock fractures and joints
- Soil compaction
Water may continue to percolate until it reaches the water table, where it becomes groundwater, or it may move laterally as throughflow.
When water soaks in rather than running off the surface, it reaches the river more slowly, so river flow becomes more regulated and less flashy. What happens to water once it is underground is covered in Throughflow and Groundwater Flow.
Factors Affecting Infiltration Rates
Natural Factors
๐ฑ Vegetation
Plants significantly enhance infiltration by:
- Creating root channels that water can follow
- Adding organic matter that improves soil structure
- Protecting soil from raindrop impact
- Slowing surface flow, giving water more time to infiltrate
Forested areas can have infiltration rates up to 10 times higher than bare soil.
๐งฑ Soil Properties
Soil characteristics dramatically influence infiltration:
- Texture: Sand > Silt > Clay (infiltration capacity)
- Structure: Well-aggregated soils have higher infiltration
- Moisture content: Dry soils initially absorb water faster
- Organic matter: Increases pore space and infiltration
- Compaction: Squashed soil has fewer pore spaces, so water enters more slowly
Typical Infiltration Rates
Different soils and surfaces have vastly different infiltration rates:
| Soil or surface |
Typical infiltration rate |
| Sandy soil |
20-30 mm/hour |
| Forest floor |
10-15 mm/hour |
| Grassland |
5-10 mm/hour |
| Clay soil |
1-5 mm/hour |
| Bare soil |
0-5 mm/hour |
| Urban surfaces |
0-1 mm/hour |
These rates explain why flooding is more common in urban areas: when rainfall intensity exceeds infiltration capacity, the extra water cannot soak in and becomes overland flow.
Overland Flow
Overland flow occurs when rainfall cannot infiltrate into the soil and instead moves across the land surface. It reaches rivers quickly, causing rapid rises in discharge. It happens when:
- Rainfall intensity exceeds infiltration capacity
- The ground is already saturated
- The surface is impermeable (e.g., concrete, compacted soil)
- Vegetation cover is sparse or absent
Factors Affecting Overland Flow
Several factors determine whether rainfall becomes overland flow or infiltrates into the ground:
๐ง๏ธ Rainfall Characteristics
Intensity: Heavy rainfall overwhelms infiltration capacity.
Duration: Prolonged rainfall saturates soil, increasing runoff.
Distribution: Where and when rain falls affects flow patterns.
๐ฑ Surface Conditions
Vegetation: Plants slow runoff and increase infiltration.
Soil type: Sandy soils absorb water faster than clay soils.
Slope: Steeper slopes increase runoff speed and volume.
๐๏ธ Human Factors
Urbanisation: Concrete surfaces prevent infiltration.
Deforestation: Removing trees increases runoff.
Land management: Farming practices affect water movement.
Understanding Channel Flow
Once water enters a river channel, its movement is governed by different factors than overland flow. Channel flow is the primary way that water moves through a drainage basin. You met velocity and discharge (Q = A ร V) in Width, Depth, Velocity, Discharge, Wetted Perimeter and the River Channel; here the focus is on what controls how water moves within the channel.
Factors Affecting Channel Flow
The speed and volume of water in a channel depends on several key factors:
๐ Channel Geometry
Width and depth: Wider, deeper channels can carry more water.
Cross-sectional shape: Affects the wetted perimeter and hydraulic radius.
Sinuosity: Meandering channels slow flow compared to straight channels.
๐งฑ Channel Roughness
Bed material: Smooth bedrock creates less friction than boulders.
Vegetation: Plants in the channel increase roughness.
Obstacles: Debris and human structures affect flow patterns.
๐ Channel Gradient
Slope: Steeper channels have faster flow.
Profile changes: Gradient typically decreases downstream.
Local variations: Rapids, waterfalls and pools create flow diversity.
๐ How Velocity Varies Within the Channel
Water does not flow at the same speed everywhere in a channel. Friction with the bed and banks slows it down, so velocity varies:
- Across the channel (faster in the centre, slower at edges)
- Vertically (faster at surface, slower near bed)
- Along the course (generally increases downstream despite gradient decrease)
Typical velocities range from 0.1 m/s in small streams to over 3 m/s in large rivers during floods.
Human Impacts on Infiltration and Percolation
Human activities change how much water can soak into the ground. Impermeable surfaces like concrete and asphalt stop infiltration almost completely, and storm drains carry the water quickly to channels. Soil compaction from heavy machinery can reduce infiltration rates by 70-80%, and removing forest cover can reduce them by 35-50%. Less infiltration means less percolation and groundwater recharge and more overland flow. How this raises flood risk is covered in Human and Natural Causes of River Flooding.
You saw how these changes alter the shape of a storm hydrograph in The Drainage Basin and the Water Cycle: Precipitation and Interception.
Case Study Focus: The Pontbren Project, Wales
The Pontbren Project in mid-Wales demonstrates how land management can affect infiltration and river discharge. In this upland sheep farming area, farmers planted native woodland and hedgerows and created shelter belts for livestock.
Key findings:
- Areas with trees had infiltration rates 60 times higher than grazed pasture
- Tree planting reduced peak flows in streams by 40% during heavy rainfall
- Soil under trees contained 30% more organic matter, improving structure and water-holding capacity
- The project reduced localised flooding and soil erosion while providing wildlife habitat
This case study shows how natural solutions can enhance infiltration and percolation, reducing flood risk downstream while providing multiple environmental benefits. Other ways of increasing infiltration, such as permeable paving and Sustainable Urban Drainage Systems (SUDS), are covered in Managing River Flooding: Hard, Soft and Sustainable Strategies.
Measuring and Monitoring Infiltration
Geographers and hydrologists use several methods to measure infiltration rates:
๐ฌ Field Techniques
- Ring infiltrometers: Metal rings inserted into soil with water added to measure infiltration rate
- Rainfall simulators: Devices that create artificial rainfall to measure infiltration under controlled conditions
- Soil moisture sensors: Electronic devices that monitor water content at different soil depths
๐ Analysing Results
Infiltration data helps geographers:
- Predict how catchments will respond to rainfall events
- Identify areas at risk of surface runoff and erosion
- Plan sustainable land management practices
- Model the effects of climate change on river systems
Summary
- Infiltration is water entering the soil; percolation is water moving down through soil and rock towards the water table
- Infiltration rates depend on soil type, moisture, vegetation, slope and rainfall intensity
- Overland flow happens when rainfall exceeds infiltration capacity, the ground is saturated or the surface is impermeable, and it reaches rivers quickly
- Channel flow is controlled by channel geometry, roughness and gradient, and velocity is fastest in the centre and near the surface
- Urbanisation, compaction and deforestation reduce infiltration, increasing runoff and flood risk
