Unlock This CourseSediment particle analysis is a fundamental technique in marine science that helps us understand underwater ecosystems. By examining the size, shape and composition of particles on the seabed, scientists can learn about water currents, marine life habitats and environmental conditions. This practical investigation teaches you how to collect, measure and interpret sediment data like a real marine biologist.
Key Definitions:
Different marine creatures prefer different types of seabed. Crabs love sandy areas for burrowing, whilst sea anemones prefer rocky surfaces for attachment. By analysing sediment, we can predict which animals might live in different areas of the ocean floor.
Before you can analyse sediment particles, you need to collect samples properly. The method you choose depends on whether you're working in shallow water, deep water, or from the shore.
There are several ways to collect sediment samples, each suited to different marine environments and research goals.
Using a grab sampler or scoop to collect surface sediment. Best for shallow water and accessible areas. Simple but effective for basic analysis.
Pushing a tube into the sediment to collect a vertical section. Shows layers of sediment over time and is excellent for detailed studies.
Collecting sediment from marked square areas. Helps ensure consistent sample sizes and allows for statistical comparison between sites.
Always wear appropriate safety equipment when collecting marine sediment samples. This includes waterproof gloves, non-slip footwear and life jackets when working near water. Never work alone and always inform someone of your sampling location and expected return time.
Once you've collected your sediment samples, it's time to analyse them in the laboratory. There are several methods for measuring particle size, from simple visual inspection to sophisticated mechanical analysis.
The most common method for analysing sediment particles uses a series of sieves with different mesh sizes. This mechanical separation technique is reliable, repeatable and doesn't require expensive equipment.
Equipment needed:
1. Preparation: Dry your sediment sample completely and weigh it accurately.
2. Sieving: Stack sieves from largest to smallest mesh size and shake for 10-15 minutes.
3. Weighing: Carefully weigh the sediment retained on each sieve.
4. Calculation: Calculate the percentage of each particle size fraction.
Marine scientists use a standard system to classify sediment particles based on their size. This system, called the Wentworth scale, helps researchers communicate clearly about different types of sediment.
This internationally recognised scale divides sediment particles into categories based on their diameter in millimetres.
Gravel: >2mm
Very coarse sand: 1-2mm
Coarse sand: 0.5-1mm
Found in high-energy environments with strong currents.
Medium sand: 0.25-0.5mm
Fine sand: 0.125-0.25mm
Common in moderate-energy beach and shallow marine environments.
Very fine sand: 0.063-0.125mm
Silt: 0.004-0.063mm
Clay: <0.004mm
Found in low-energy, deep-water environments.
The real skill in sediment analysis comes from interpreting what your particle size data tells you about the marine environment. Different patterns reveal different stories about water energy, transport processes and ecosystem conditions.
A study comparing sediment from a rocky shore and nearby sandy beach revealed fascinating differences. The rocky shore had 65% gravel and coarse sand, indicating high wave energy that washes away fine particles. The sandy beach showed 80% medium to fine sand, suggesting moderate wave action that sorts particles by size. These different substrates support completely different communities of marine life.
Particle size distribution tells us about the energy of the marine environment and the types of organisms that can survive there.
Dominated by coarse particles (gravel and coarse sand). Strong currents and waves wash away fine material. Home to organisms that can withstand turbulent conditions, like barnacles and mussels that attach firmly to hard surfaces.
Rich in fine particles (silt and clay). Calm conditions allow small particles to settle. Support burrowing organisms like worms and clams that can filter food from the water and sediment.
Sediment particle analysis isn't just an academic exercise - it has real-world applications in marine conservation, coastal management and environmental monitoring.
Changes in sediment composition can indicate environmental problems. For example, an increase in fine particles might suggest increased erosion from coastal development, whilst changes in organic content could indicate pollution.
Monitoring applications include:
In the Great Barrier Reef, scientists use sediment analysis to monitor the health of coral ecosystems. Increased fine sediment from agricultural runoff can smother coral polyps and block sunlight needed for photosynthesis. Regular sediment monitoring helps identify problem areas and guide conservation efforts.
Like any scientific technique, sediment particle analysis can present challenges. Understanding these potential problems and their solutions will help you conduct more accurate investigations.
Even experienced researchers encounter problems during sediment analysis. Here are some common issues and how to solve them.
Shell fragments and organic matter can affect results. Remove large shells and organic debris before analysis, but record their presence as they're part of the ecosystem story.
Clay particles may stick together or to larger grains. Pre-treat samples with dispersing agents and ensure thorough mixing before sieving.
Blocked sieves give inaccurate results. Clean sieves thoroughly between samples and check for damage. Replace worn meshes promptly.
Proper data recording and presentation are essential skills for any marine scientist. Your results need to be clear, accurate and easy for others to understand and verify.
Create clear tables showing particle size fractions and percentages. Use graphs to visualise your results - histograms work well for showing particle size distribution. Always include error bars and sample sizes in your presentations.
