What you'll learn this session

Study time: 30 minutes

  • The structure and function of the human breathing system
  • How the lungs are protected and supported
  • The mechanics of breathing (inhalation and exhalation)
  • The role of the diaphragm and intercostal muscles
  • How breathing rate is controlled
  • Lung volumes and breathing measurements

Introduction to Human Breathing Mechanisms

Breathing is something we do without thinking, about 20,000 times a day! But how exactly does air move in and out of our lungs? In this section, we'll explore the amazing mechanisms that allow us to breathe and how our body controls this vital process.

Key Definitions:

  • Breathing (ventilation): The process of moving air in and out of the lungs.
  • Inhalation (inspiration): The process of taking air into the lungs.
  • Exhalation (expiration): The process of releasing air from the lungs.
  • Diaphragm: A dome-shaped muscle that separates the chest cavity from the abdominal cavity.
  • Intercostal muscles: Muscles found between the ribs that help with breathing.

The Breathing System Structure

Before we dive into how breathing works, let's look at the key parts of the breathing system:

🔑 The Respiratory Tract

The respiratory tract is divided into two main sections:

  • Upper respiratory tract: Includes the nose, nasal cavity and pharynx (throat).
  • Lower respiratory tract: Includes the larynx (voice box), trachea (windpipe), bronchi, bronchioles and lungs.

Air travels through these structures during breathing, getting warmed, moistened and filtered along the way.

🌱 The Lungs

The lungs are the main organs of respiration. They are:

  • Protected by the ribcage
  • Covered by two membranes called pleura
  • Filled with millions of tiny air sacs called alveoli
  • Elastic and spongy to allow expansion and contraction
  • Located in the thoracic (chest) cavity

The Mechanics of Breathing

Breathing involves two phases: inhalation (breathing in) and exhalation (breathing out). Both processes rely on pressure changes in the thoracic cavity.

Inhalation (Breathing In)

Inhalation is an active process that requires muscular effort. Here's what happens:

💪 Muscle Action

The diaphragm contracts and flattens, moving downward. The external intercostal muscles contract, pulling the ribcage up and out.

📐 Volume Change

These muscle movements increase the volume of the thoracic cavity, creating more space for the lungs to expand into.

💨 Pressure Change

As volume increases, the pressure inside the lungs decreases (below atmospheric pressure), causing air to rush in from outside.

Exhalation (Breathing Out)

Exhalation is usually a passive process during normal breathing. Here's what happens:

💪 Muscle Relaxation

The diaphragm relaxes and moves upward (dome shape). The external intercostal muscles relax, allowing the ribcage to move down and in.

📐 Volume Change

These movements decrease the volume of the thoracic cavity, reducing the space available for the lungs.

💨 Pressure Change

As volume decreases, the pressure inside the lungs increases (above atmospheric pressure), forcing air out.

Did You Know? Forced Breathing

During exercise or when we need more oxygen, we use forced breathing. In forced exhalation, the internal intercostal muscles and abdominal muscles actively contract to push more air out of the lungs. This makes exhalation an active process rather than passive.

The Role of Pleural Membranes

The lungs are surrounded by two thin membranes called pleura:

  • Visceral pleura: Attached to the outer surface of the lungs
  • Parietal pleura: Attached to the inside of the chest wall

Between these membranes is a thin space called the pleural cavity, which contains a small amount of pleural fluid. This fluid:

  • Reduces friction during breathing movements
  • Creates surface tension that helps the lungs expand and contract with the chest wall
  • Helps maintain negative pressure that prevents lung collapse

Controlling Breathing Rate

While we can consciously control our breathing to some extent, most of the time it's regulated automatically by the brain.

🔋 The Breathing Control Centre

Breathing is controlled by the respiratory centre in the medulla oblongata of the brain. This centre:

  • Monitors carbon dioxide levels in the blood
  • Sends nerve impulses to the breathing muscles
  • Automatically adjusts breathing rate and depth as needed

📈 Factors Affecting Breathing Rate

Several factors can change how fast and deep we breathe:

  • Exercise: Increases breathing rate to supply more oxygen to muscles
  • Carbon dioxide levels: Higher CO₂ levels trigger faster breathing
  • Oxygen levels: Low O₂ can increase breathing rate (but less sensitive than CO₂)
  • Emotions: Fear, anxiety, or excitement can speed up breathing
  • Temperature: Fever can increase breathing rate

Case Study: Asthma and Breathing Mechanics

Asthma is a common condition that affects the breathing mechanisms we've discussed. During an asthma attack:

  • The muscles around the bronchioles constrict (bronchoconstriction)
  • The lining of the airways becomes inflamed and swollen
  • Excess mucus is produced

These changes narrow the airways, making it harder to breathe out (exhalation becomes difficult). People with asthma often use inhalers containing bronchodilators that relax the muscles around the airways, making breathing easier.

Measuring Breathing

Scientists and doctors measure different aspects of breathing using a device called a spirometer. Here are some important measurements:

📊 Lung Volumes

Key measurements include:

  • Tidal volume: The amount of air breathed in or out during normal breathing (about 500ml)
  • Vital capacity: The maximum amount of air that can be exhaled after taking the deepest possible breath (about 4-5 litres in adults)
  • Residual volume: The air that remains in the lungs even after the most forceful exhalation

Breathing Rate

Normal breathing rates vary by age:

  • Adults: 12-20 breaths per minute
  • Children: 15-30 breaths per minute
  • Infants: 30-60 breaths per minute

During exercise, breathing rate can increase to 40-60 breaths per minute to meet the body's increased oxygen demand.

Summary of Breathing Mechanisms

Breathing is a complex but beautifully coordinated process that involves:

  • Muscle movements that change the volume of the thoracic cavity
  • Pressure changes that drive air flow into and out of the lungs
  • Automatic control by the respiratory centre in the brain
  • Adjustments based on the body's changing needs

Understanding these mechanisms helps us appreciate how our body maintains the constant gas exchange needed for survival and how problems with these mechanisms can lead to respiratory disorders.
