What you'll learn this session

Study time: 30 minutes

  • What pyramids of number represent in ecosystems
  • How to construct and interpret pyramids of number
  • Why some pyramids of number have unusual shapes
  • The limitations of pyramids of number
  • How pyramids of number relate to energy flow in ecosystems

Introduction to Pyramids of Number

In ecosystems, organisms interact with each other through feeding relationships. These relationships can be represented visually using ecological pyramids. A pyramid of number is one type of ecological pyramid that shows the number of individual organisms at each trophic level in an ecosystem.

Key Definitions:

  • Pyramid of number: A diagram showing the number of individual organisms at each trophic level in an ecosystem.
  • Trophic level: The position an organism occupies in a food chain.
  • Producer: An organism that makes its own food through photosynthesis.
  • Consumer: An organism that feeds on other organisms.

🌾 Understanding Trophic Levels

Before we dive into pyramids of number, let's make sure we understand trophic levels:

  • Producers (1st trophic level): Plants and algae that convert sunlight into energy through photosynthesis
  • Primary consumers (2nd trophic level): Herbivores that eat producers
  • Secondary consumers (3rd trophic level): Carnivores that eat primary consumers
  • Tertiary consumers (4th trophic level): Carnivores that eat secondary consumers

📚 Why Study Pyramids?

Pyramids of number help us:

  • Visualise the structure of an ecosystem
  • Understand feeding relationships
  • See how energy flows through an ecosystem
  • Predict how changes might affect different trophic levels
  • Compare different ecosystems

Constructing Pyramids of Number

A pyramid of number is drawn with horizontal bars representing each trophic level. The width of each bar is proportional to the number of individual organisms at that level. The producers form the base of the pyramid, with successive trophic levels stacked above.

To construct a pyramid of number:

  1. Count the number of individual organisms at each trophic level
  2. Draw horizontal bars with widths proportional to these numbers
  3. Stack the bars with producers at the bottom and top predators at the top
  4. Label each bar with the trophic level and number of organisms

Worked Example: Grassland Ecosystem

Let's construct a pyramid of number for a simple grassland ecosystem:

  • Producers: 10,000 grass plants
  • Primary consumers: 1,000 grasshoppers
  • Secondary consumers: 100 frogs
  • Tertiary consumers: 10 hawks

This forms a typical pyramid shape, with the number of organisms decreasing as you move up the trophic levels.

Different Shapes of Pyramids of Number

While many pyramids of number have a classic pyramid shape (wide at the base, narrow at the top), some ecosystems produce differently shaped pyramids.

🟢 Upright Pyramid

Most common shape where the number of organisms decreases at each higher trophic level. Example: grassland ecosystem with many grass plants, fewer grasshoppers, even fewer frogs and very few hawks.

🔴 Inverted Pyramid

When there are fewer producers than consumers. Example: a tree with thousands of insects feeding on it. One producer (the tree) supports many primary consumers (insects).

🟡 Spindle-shaped Pyramid

When middle trophic levels have more organisms than both lower and higher levels. Example: parasitic food chain where a few large hosts support many small parasites, which in turn support fewer predators.

Why Do Some Pyramids Have Unusual Shapes?

The shape of a pyramid of number depends on several factors:

🌲 Size of Organisms

Large producers (like trees) can support many smaller consumers, creating an inverted pyramid. A single oak tree might support thousands of caterpillars, creating a pyramid that's wider at the second level than at the base.

🚀 Reproduction Rate

Organisms with high reproduction rates can maintain large populations despite predation. For example, a small number of phytoplankton can reproduce so rapidly that they support a larger number of zooplankton, temporarily creating an inverted pyramid.

Case Study: The Oak Tree Ecosystem

An oak tree ecosystem demonstrates an inverted pyramid of number:

  • Producers: 1 oak tree
  • Primary consumers: 10,000+ caterpillars and other insects
  • Secondary consumers: 100 birds
  • Tertiary consumers: 5 hawks

This inverted pyramid occurs because a single large producer (the oak tree) can support thousands of smaller primary consumers. However, the pyramid of biomass for this same ecosystem would likely be upright, as the tree has more biomass than all the insects combined.

Limitations of Pyramids of Number

While pyramids of number are useful tools, they have several limitations:

  • Size differences: They don't account for the size of organisms. One large producer might support many small consumers.
  • Seasonal variations: Numbers of organisms can change dramatically with seasons.
  • Incomplete picture: They don't show energy transfer or biomass, which are often more important for understanding ecosystem function.
  • Difficult to count: It's challenging to count all individuals in an ecosystem, especially microscopic organisms.
  • Organisms in multiple trophic levels: Some organisms feed at different trophic levels at different life stages or times.

Comparing Pyramids of Number with Other Ecological Pyramids

Pyramids of number are just one way to represent feeding relationships. They can be compared with other types of ecological pyramids:

📊 Pyramids of Number

Show the count of individual organisms at each trophic level. Can be inverted in some ecosystems. Easy to understand but doesn't account for organism size.

⚖ Pyramids of Biomass

Show the total dry mass of organisms at each trophic level. Usually upright, but can be inverted in aquatic ecosystems. Better represents the amount of living material.

⚡ Pyramids of Energy

Show the energy flow at each trophic level. Always upright due to energy loss between levels. Most accurate representation of ecosystem function.

Applying Your Knowledge

Understanding pyramids of number helps us interpret ecosystems and predict how changes might affect them. For example:

  • Conservation: If a predator species is endangered, a pyramid of number can help predict how its decline might affect prey populations.
  • Pest control: Understanding the number relationships between pests and their predators can help develop biological control strategies.
  • Ecosystem management: Pyramids can help identify which trophic levels might be most vulnerable to disturbance.

Exam Tip!

In your IGCSE Biology exam, you might be asked to:

  • Draw a pyramid of number from given data
  • Explain why a pyramid has a particular shape
  • Compare different types of ecological pyramids
  • Describe the limitations of pyramids of number

Remember that not all pyramids of number have a typical pyramid shape and be prepared to explain why!

Summary

Pyramids of number are valuable tools for visualising the structure of ecosystems. They show the number of individual organisms at each trophic level and can have different shapes depending on the ecosystem. While they have limitations, especially when comparing organisms of very different sizes, they provide important insights into feeding relationships and ecosystem structure.

Remember that pyramids of number should be considered alongside other ecological pyramids (biomass and energy) to get a complete picture of how an ecosystem functions.
