🌊 Major Water Stores
The oceans hold about 97% of Earth's water, making them by far the largest store. Ice caps and glaciers contain most of the fresh water, whilst rivers and lakes hold much smaller amounts but are crucial for human use.
The Hydrological Cycle » Water Stores and Transfers
What you'll learn this session
Study time: 30 minutes
- Understand the different water stores in the hydrological cycle
- Learn about water transfers and how water moves between stores
- Explore the processes of evaporation, condensation, precipitation and infiltration
- Examine case studies showing water stores and transfers in action
- Analyse how human activities affect the hydrological cycle
Introduction to Water Stores and Transfers
The hydrological cycle is like a giant recycling system for water on Earth. Water constantly moves between different stores through various transfer processes. Think of it as nature's way of moving water around the planet - from oceans to clouds, from rivers to underground and back again. This endless cycle has been happening for millions of years and keeps our planet's water supply fresh and moving.
Key Definitions:
- Water Store: A place where water is held or stored, such as oceans, rivers, lakes, ice caps, or underground.
- Water Transfer: The movement of water from one store to another through processes like evaporation, precipitation, or flow.
- Hydrological Cycle: The continuous movement of water through different stores on Earth.
- Residence Time: How long water typically stays in a particular store before moving on.
The Main Water Stores
Water on Earth is stored in several different places, each with unique characteristics and importance. Understanding these stores helps us see how water moves around our planet and why some areas have more water available than others.
Oceanic Stores
Oceans are the largest water stores on Earth, containing about 1.37 billion cubic kilometres of water. This saltwater covers roughly 71% of Earth's surface and plays a massive role in regulating global climate. The Pacific Ocean alone holds more water than all other stores combined.
🌊 Oceans
97% of all water. Saltwater that drives global weather patterns through evaporation and heat storage.
❄ Ice Caps & Glaciers
2% of all water. Frozen freshwater mainly in Antarctica and Greenland, acting as long-term storage.
Groundwater
0.6% of all water. Freshwater stored underground in rocks and soil, crucial for wells and springs.
Atmospheric and Surface Stores
Though these stores contain relatively small amounts of water, they're incredibly important for life on Earth. Rivers, lakes and atmospheric moisture provide the water we see and use daily.
🌊 Lakes
Freshwater bodies that store water temporarily. Examples include the Great Lakes and Lake Baikal.
🌊 Rivers
Moving freshwater that transports water from land back to oceans. Think Thames or Amazon.
☁ Atmosphere
Water vapour and droplets in air. Small amount but vital for weather and precipitation.
Case Study Focus: The Amazon Basin
The Amazon rainforest demonstrates multiple water stores working together. The Amazon River system stores and transfers huge amounts of water, whilst the forest canopy intercepts rainfall. Underground, vast aquifers store groundwater. The trees themselves act as biological water stores, holding water in their trunks and leaves. This creates a complex system where water constantly moves between atmospheric, surface, biological and underground stores.
Water Transfer Processes
Water doesn't just sit still in these stores - it's constantly moving between them through various transfer processes. These transfers are powered by energy from the sun and gravity, creating the dynamic hydrological cycle we observe.
Evaporation and Transpiration
These processes move water from surface stores into the atmosphere. Evaporation happens when the sun heats water in oceans, lakes and rivers, turning it into invisible water vapour. Transpiration occurs when plants release water vapour through their leaves. Together, these processes are called evapotranspiration.
☀ Evaporation Factors
Temperature, wind speed, humidity and surface area all affect how quickly water evaporates. Hot, windy, dry conditions speed up evaporation, whilst cool, calm, humid conditions slow it down.
Condensation and Precipitation
When water vapour in the atmosphere cools down, it condenses back into tiny water droplets, forming clouds. When these droplets get heavy enough, they fall as precipitation - rain, snow, sleet, or hail. This transfers water from the atmospheric store back to surface stores.
🌧 Rain
Liquid precipitation that occurs when temperatures are above freezing. Most common in temperate regions.
❄ Snow
Frozen precipitation that falls when temperatures are below freezing. Common in polar and mountain regions.
🌨 Hail
Ice pellets formed in thunderstorms when raindrops freeze and refreeze as they move up and down in clouds.
Surface and Subsurface Transfers
Once water reaches the ground, it can follow several paths. Some flows over the surface as runoff, eventually reaching rivers and streams. Other water soaks into the ground through infiltration, becoming soil moisture or groundwater.
🌊 Surface Runoff
Water that flows over the ground surface when soil becomes saturated or impermeable. This includes overland flow and stream flow that eventually reaches the sea.
Case Study Focus: UK Water Transfers
The UK demonstrates various water transfers throughout the year. In winter, Atlantic weather systems bring moist air that condenses over hills and mountains, creating orographic rainfall. This precipitation fills reservoirs in areas like the Lake District and Welsh valleys. During summer, higher temperatures increase evaporation from these water bodies, whilst transpiration from vegetation peaks. Rivers like the Thames show seasonal variations in flow, with high discharge in winter from increased precipitation and lower flows in summer due to reduced rainfall and higher evapotranspiration rates.
Human Impact on Water Stores and Transfers
Human activities significantly affect how water moves through the hydrological cycle. We build dams to create artificial stores, drain wetlands and cover land with concrete, all of which change natural water transfers.
Urbanisation Effects
Cities dramatically alter local water cycles. Concrete and tarmac create impermeable surfaces that prevent infiltration, increasing surface runoff. This can lead to flash flooding during heavy rainfall as water cannot soak into the ground naturally.
🏢 Impermeable Surfaces
Roads, pavements and buildings prevent water infiltration, forcing more water to flow as surface runoff.
🌊 Storm Drains
Artificial channels that quickly move urban runoff to rivers, reducing natural storage time in soil.
🌱 Reduced Vegetation
Less transpiration and interception in cities compared to natural areas, altering local humidity and rainfall patterns.
Agricultural Impacts
Farming practices change water transfers through irrigation, drainage and land use changes. Irrigation moves water from rivers and groundwater to crop stores, whilst drainage systems speed up water movement from fields to rivers.
🌾 Irrigation Systems
Artificial water transfers that move water from stores like rivers and aquifers to agricultural land. This can deplete natural water stores if overused.
Case Study Focus: Three Gorges Dam, China
The Three Gorges Dam on the Yangtze River creates a massive artificial water store - a reservoir 660km long. This dam significantly alters natural water transfers by controlling river flow, reducing flood peaks downstream and increasing evaporation from the enlarged water surface. The dam demonstrates how humans can create new water stores and modify transfer processes, though this comes with environmental consequences including altered sediment transport and changed flood patterns downstream.
Measuring and Monitoring Water Stores
Scientists use various methods to measure water in different stores and track how it moves between them. This data helps us understand climate change impacts and manage water resources effectively.
Monitoring Techniques
From satellite imagery tracking ice cap changes to river gauges measuring flow rates, technology helps us monitor the hydrological cycle. Weather stations record precipitation and evaporation, whilst groundwater monitoring wells track subsurface water levels.
🛰 Satellite Monitoring
Satellites can measure soil moisture, track cloud formation, monitor ice cap thickness and observe changes in large water bodies over time.
